Steel Grating for Drain Trench, Drainage Cover
Hengshui Zeqian Technology Co., Ltd.- Material:Stainless Steel or Hot DIP Galvanized
- Application:Alloys, Building Materials,and Drain
- Surface Treatment:Polished
- Sink Strainer Kind:Push Down Pop-up
- Kind:Manhole Cover
- Indoor/Outdoor:Outdoor
Base Info
- Model NO.:150
- Odour Proof:Not Odour Proof
- Style:Push Down Pop-up
- Color:Silver
- Wastewater Type:Rain
- Transport Package:Wooden Pallet
- Specification:Can be Custom made
- Trademark:HZT
- Origin:China
- Production Capacity:200PCS,Week
Description
Basic Info.
Model NO. 150 Odour Proof Not Odour Proof Style Push Down Pop-up Color Silver Wastewater Type Rain Transport Package Wooden Pallet Specification Can be Custom made Trademark HZT Origin China Production Capacity 200PCS/WeekProduct Description
1) Bearing Bar (Load Bar) Specifications (mm):The specification of plain type and serrated type bearing bar is 20 x 3 to 100 x 10; The specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, etc.
2) Bearing Bar Pitch (center to center):
12.5, 15, 25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended,
America standard is available <1'' x 3/16'', 1 1/4'' x 3/16'', 1-1/2'' x 3/16'', 1'' x 1/4'', 1-1/4'' x 1/4'', 1 1/2'' x 1/4''(19-w-4) and so on. >
3) Cross Bar Pitch (center to center):
38.1, 40, 50, 60, 76, 80, 90, 100, 101.6, 102, 135mm and so on
4) Material:
Mild Steel (Low Carbon Steel) or Stainless Steel
5) Surface Treatment:
Untreated, Painting or Hot DIP Galvanizing
- Description:
1 material: hot dip galvanized or stainless steel
2 Cross Bar Pitch (center to center): 38.1, 40, 50, 60, 76, 80, 90, 100, 101.6, 102, 135mm and so on
No. Item Detailed Description 1 Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc; I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1' ' x3/16' ' , 1 1/4' ' x3/16' ' , 1 1/2' ' x3/16' ' , 1' ' x1/4' ' , 1 1/4' ' x1/4' ' , 1 1/2' ' x1/4' ' , 1' ' x1/8' ' , 1 1/4' ' x1/8' ' , 1 1/2' ' x1/8' ' etc2 Bearing Bar Pitch 12.5, 15, 20, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc3 Twisted Cross Bar Pitch 38.1, 40 50, 60, 76, 80, 100, 101.6, 120mm, 2' ' & 4' ' etc 4 Steel Grade ASTM A36, A1011, A569, Q235, S235JR, S275JR, SS304, Mild steel & Low carbon steel, etc 5 Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating 6 Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
FAQ:
Q1: How many years guarantee ?
2-5 years according to products standard
Q2: What is your MOQ?
Normally 100 Pcs Per Item. Trial Orders And Further Requests Can Be Negotiated.
Q3: How about the delivery time?
Normally 10-15days
Q4: Can we get sample to check quality?
Yes, we can provide the sample at the mass produced cost for you to check the quality, and will refund the sample cost when you place an order.
Q5: How many days for arranging samples?
Normally 3-5 days
Q6: What is your payment term
T/T 30% in advance, 70% remaining balance before shipment
Irrevocable L/C at sight
Q7: OEM Service
We are quite professional for OEM service for the grating cover.
Q8: Can I visit your factory? Can your factory arrange transportation for me?
It is a great honor to invite you to visit our factory, We will arrange car to pick up you from the air port..
Q9: How is your factory production capability?
15 -20 containers per month
Q10: How big is your factory?
About 6000m2
Q11: What is your terms of packing?
Generally, we pack our goods in neutral wooden case or wooden pallet. If you have legally registered patent, we can pack the goods in your requirment.
